Samsung Galaxy S4 - Replacing the USB connector

Your Samsung Galaxy S4 won’t charge

  • Galaxy S4
  • 11 Steps
  • Easy
  • 30 min.
Go to the guide

Introduction

In this guide, we show you how to replace your Samsung Galaxy S4’s defective USB connector. You need this repair if your computer doesn’t recognize your Samsung phone, or you can’t charge your phone.

Required tools

  • Heat gun

    Heat gun

    You can use a heat gun to heat parts that are glued on so they’re easier to remove. In most cases, you can also use a hairdryer.

    from €14.99 on Amazon
  • Menda ESD Spudger

    Menda ESD Spudger

    You need a flat plastic prying tool to disconnect the various plugs and connectors.

    €5.00 at the iDoc store
  • Steel Laboratory Spatula

    Steel Laboratory Spatula

    You need a flat and sturdy prying tool to disconnect glued parts.

    €9.00 at the iDoc store
  • Phillips PH00 screwdriver

    Phillips PH00 screwdriver

    You need the right screwdriver for removing PH00 screws.

    €10.00 at the iDoc store

Required replacement part

Show all replacement parts for the Galaxy S4

Replacement parts and tools for this repair

Our tools plus the right spare part help you fix your device easily.

Werkzeugset Samsung

Ganz gleich, welches Problem dein Handy hat - mit unserem Werkzeugset kannst du es bestimmt beheben. Dieses Reparaturset...

for €49.00

Getting started

If you get stuck or have questions, you can post a comment for each step. We’d be happy to help.

11 steps
  1. Removing the back cover

    Galaxy S4 - Removing the back cover 01
    Galaxy S4 - Removing the back cover 02
    1. Insert the spudger into the gap next to the headphones. There are 16 clips on the outside under the back cover. You have to disconnect them by moving the spudger around the entire smartphone one time. Alternatively, you can detach the back cover using your fingernails.
    2. Then you can take off the back cover.
  2. Removing the battery

    Galaxy S4 - Removing the battery 01
    Galaxy S4 - Removing the battery 02
    1. If your Samsung Galaxy’s still on, turn it off by holding down the standby button for about three seconds and following the prompt on the display.
    2. Now use the spudger or your fingertip to lift the battery (see figure 1) and then remove it (see figure 2).
  3. Removing the SIM card

    Galaxy S4 - Removing the SIM card 01
    Galaxy S4 - Removing the SIM card 02
    1. Use the spudger or your finger to push the SIM card all the way into the slot (see figure 1). After a gentle click, the SIM card will come out (see figure 2).
    2. Now you can pull it out with your fingers.
    3. Repeat this process if you’ve installed a microSD card.
  4. Removing the plastic cover

    Galaxy S4 - Removing the plastic cover 01
    Galaxy S4 - Removing the plastic cover 02
    Galaxy S4 - Removing the plastic cover 03
    Galaxy S4 - Removing the plastic cover 04
    Galaxy S4 - Removing the plastic cover 05
    Galaxy S4 - Removing the plastic cover 06
    1. Remove the 9 Phillips screws that hold the plastic cover in place (see figure 1).
      9 x 4.0 mm Phillips screws
    2. Lift the cover and the chrome frame to remove them. The cover is attached to the display at 14 points. Insert the spudger between the chrome frame and the display. Start at the level of the Home button (see figure 2) and move the spudger once around the entire phone to detach all connections (see figures 3 and 4). Then you can remove the midframe.
  5. Removing the USB connector

    Galaxy S4 - Removing the USB connector 01
    Galaxy S4 - Removing the USB connector 02
    Galaxy S4 - Removing the USB connector 03
    Galaxy S4 - Removing the USB connector 04
    Galaxy S4 - Removing the USB connector 05
    1. First disconnect the following cables. Place the flat end of the spudger very slightly below the contact and lift it up (see figures 1 to 3).
      Touch button cable
      Antenna cable
    2. Now remove the bracket over the USB port by inserting the pointed tip of the spudger between the USB port and the bracket and lifting the bracket with some force (see figure 4). Put the bracket in a compartment of your organizer tray.
    3. Insert the spudger below the USB connector cable and carefully detach it from the base (see figure 5). It’s lightly glued in place.
    4. Now carefully remove it by hand.
    5. In some cases, you may have to remove the adhesive film below it.
  6. Installing the USB connector

    Galaxy S4 - Installing the USB connector 01
    Galaxy S4 - Installing the USB connector 02
    Galaxy S4 - Installing the USB connector 03
    1. Now put the USB connector cable set back in the appropriate position (see figure 1).
    2. If the cable set is fitted correctly, you can clamp the bracket over the USB port again (see figure 2).
    3. Connect the blue antenna cable and then put it back in the cable guide. Be very careful because the contacts could bend if they’re not connected right (see figure 3).
    4. Install the touch button cable again (see figure 3).
  7. Attaching the plastic cover

    Galaxy S4 - Attaching the plastic cover 01
    1. Now put on the plastic cover and make sure that it clicks into place properly on all sides.
    2. Then screw it on.
      9 x 4.0 mm Phillips screws
  8. Inserting the SIM and microSD cards

    Galaxy S4 - Inserting the SIM and microSD cards 01
    1. Now slide the SIM card and the microSD card, if you have one, back into the corresponding slots.
  9. Installing the battery

    Galaxy S4 - Installing the battery 01
    1. Put the battery back in. The +/- symbols have to be touching the contact point.
  10. Attaching the back cover

    Galaxy S4 - Attaching the back cover 01
    1. It’s very easy to put the back cover back on. Put it on in the correct position and press it on all the way around the phone until it’s completely clicked into place.
  11. Final test

    1. Start your Samsung Galaxy S4 and enter the following key combination:
      *#0*#
    2. Then press the call button.
    3. Now you can check all the functions.
